This demo showcases how to add metrics on the spring-retry functionality with the micrometer library.

The project spring-retry offers both declarative and imperative retry support for spring applications.

Below is presented a simple code snippet to get an idea about how the imperative retry support can be configured for a retriable functionality:

RetryTemplate template = RetryTemplate.builder()
				.maxAttempts(3)
				.fixedBackoff(1000)
				.retryOn(RemoteAccessException.class)
				.build();

template.execute(ctx -> {
    // ... do something
});

Coupling together spring AOP and spring-retry gives the ability to perform retries on the public method calls that correspond to a pointcut. This could come pretty handy when dealing with a class or a set of classes which expose the API of an external service.

Due to various reasons, every now and then it happens that an API call doesn’t succeed, but when trying again everything works just fine.

This post showcases the ability to collect metrics via micrometer library on:

• how many calls to the external API were successful
• how many calls to the external API were retried once, twice, three times
• how many calls to the external API have failed and with which exception type

The project spring-retry-metrics is referenced throughout this blog post in order to have a concrete implementation of the concepts presented.

For the sake of a concrete example of an external API, the project spring-retry-metrics makes use of a slimmed mocked version of the Github API. No actual calls towards Github API are made during the tests of this project.

Below is presented a test scenario from the project for showing at work both the spring-retry functionality (the Github repository details are retrieved successfully, even though the first call to the Github API fails) and the metrics of the spring-retry functionality on the methods advised via spring AOP for the class com.findinpath.github.api.GithubApi

GithubApiRetryTest.java

  @Test
  public void firstApiOperationCallFails() throws Exception {
    var blogRepository = new GithubRepository(BLOG_REPOSITORY_NAME,
        new URL("https://github.com/findinpath/blog"),
        false);

    when(restClient.getForEntity(
        eq(API_URL + "orgs/" + ORGANISATION_NAME + "/repos/" + BLOG_REPOSITORY_NAME),
        eq(GithubRepository.class))
    )
    .thenThrow(new IllegalStateException("Internal server error"))
    .thenReturn(blogRepository);

    var repository = githubApi.getOrganisationRepository(ORGANISATION_NAME, BLOG_REPOSITORY_NAME);
    assertThat(repository, equalTo(blogRepository));

    // check that the metrics are collected as expected
    var meters = meterRegistry.getMeters();
    var githubApiTimer = getExactlyOneMeter(meters, API_METRIC_NAME,
        Timer.class,
        Tag.of("exception", "none"),
        Tag.of("class", "GithubApi"),
        Tag.of("method", "getOrganisationRepository"));
    var githubApiExceptionTimer = getExactlyOneMeter(meters, API_METRIC_NAME,
        Timer.class,
        Tag.of("exception", "IllegalStateException"),
        Tag.of("class", "GithubApi"),
        Tag.of("method", "getOrganisationRepository"));
    var githubApiRetryTimer = getExactlyOneMeter(meters, API_RETRY_METRIC_NAME,
        Timer.class,
        Tag.of("class", "GithubApi"),
        Tag.of("method", "getOrganisationRepository"));

    assertThat(githubApiTimer.count(), equalTo(1L));
    assertThat(githubApiExceptionTimer.count(), equalTo(1L));
    assertThat(githubApiRetryTimer.count(), equalTo(1L));
    assertThat(githubApiRetryTimer.max(TimeUnit.MILLISECONDS),
        greaterThan(githubApiTimer.max(TimeUnit.MILLISECONDS)));
    assertThat(githubApiRetryTimer.max(TimeUnit.MILLISECONDS),
        greaterThan((double) GithubApiRetryTest.TestConfiguration.INITIAL_BACKOFF_TIME));

    var githubApiRetriesCounter = getExactlyOneMeter(meters, API_METRIC_NAME + "_retries",
        Counter.class,
        Tag.of(MicrometerRetryListenerSupport.CLASS_TAG_NAME, "GithubApi"),
        Tag.of(MicrometerRetryListenerSupport.METHOD_TAG_NAME, "getOrganisationRepository"),
        Tag.of(MicrometerRetryListenerSupport.RETRY_TAG_NAME, "1"),
        Tag.of(MicrometerRetryListenerSupport.EXCEPTION_TAG_NAME, "IllegalStateException"));
    assertThat(githubApiRetriesCounter.count(), equalTo((double) 1));

  }

Spring AOP configuration

The following Spring AOP configuration serves for the following purposes:

• times how long each Github API call takes to complete including internal retries (in case that the first,second, … call to the API doesn’t succeed)
• adds spring-retry functionality on all exposed Github API calls
• times how long each Github API call takes to complete

github-api-aop-config.xml

  <aop:config>
    <aop:pointcut id="github-api-calls"
      expression="execution(* com.findinpath.github.api.GithubApi.*(..))  "/>

    <!--
    the githubApiRetriesIncludedTimedAdvice advice wraps
    the githubApiRetryAdvice advice and this it can provide
    timing information for the duration of the API call
    including retries
     -->
    <aop:advisor pointcut-ref="github-api-calls"
      advice-ref="githubApiRetriesIncludedTimedAdvice" order="1"/>
    <aop:advisor pointcut-ref="github-api-calls"
      advice-ref="githubApiRetryAdvice" order="2"/>
    <!--
    timing advice for each (retries are not taken into account)
    of the Github API calls.
    -->
    <aop:advisor pointcut-ref="github-api-calls"
      advice-ref="githubApiTimedAdvice" order="3"/>

  </aop:config>

Notice on the configuration above that several Spring AOP advisors are stacked like ognion layers on top of each other. The precedence of the advisor is determined by the order parameter of the advisor.

Spring-retry enhancements

At the time of this writing, spring-retry library in the version 1.2.4.RELEASE doesn’t provide the ability to retrieve information about the invoked method (see org.aopalliance.intercept.MethodInvocation) in the spring AOP context. See the corresponding Github issue

This limitation doesn’t allow to access the invoked class and method name in the concrete implementations of the org.springframework.retry.listener.RetryListenerSupport defined for the spring-retry’s RetryTemplate. What this means is that when a spring-retry failure occurs on a specific API call, we only would know in the monitoring that one of the API calls failed, but not exactly which. For our concrete example, if Github API has several exposed endpoints, it would be surely important to know via monitoring dashboards which one of these endpoints is causing failures in our application.

In order to enhance the metrics collected for the methods advised with spring-retry functionality, the project spring-retry-metrics has performed a little enhancement on the default spring-retry functionality by adding the MethodInvocation of the advised method to the retry context.

See the code source for the class org.springframework.retry.interceptor.MethodInvocationRetryOperationsInterceptor for more details.

Run the project

Run the command

mvn clean install

for executing the tests from this project.
